AACF/Changing Places Hoists

BCA 2019 COMPLIANT

Overview

Para Mobility has a number of Ceiling Hoists that comply with BCA 2019 specifications

It is a basic human right to be able to access a clean, safe and private place to go to the toilet.

Australia became the first country in the world to regulate for adult change facilities [AACF] in its building code. From 1 May 2019, the National Construction Code (NCC 2019) required a new type of public toilet called ‘Accessible Adult Change Facilities’ [AACF] – based on the Changing Places design – to be included in certain classes of public buildings such as:

  • shopping centres
  • sports stadiums and swimming pools
  • theatres and museums
  • domestic and international airports

(a) Each accessible adult change facility [AACF] must—

(i) be constructed so that all required equipment and fixtures are contained within the same room; and
(ii) if it is a unisex facility, be located such that it can be entered without crossing an area reserved for one sex only.

(b) In each accessible adult change facility, the following must be provided:

(i) A hoist complying with Clause 3 – see details below
(ii) A toilet pan, seat, backrest and grabrails complying with Clause 4
(iii) A washbasin and tap complying with Clause 5
(iv) Fixtures and fittings as specified in Clause 6
(v) A change table complying with Clause 7 – see details below
(vi) Changing rails complying with Clause 8
(vii) An automated entrance door complying with Clause 9
(viii) Signage complying with Clause 10
(ix) Operating instructions for the hoist and change table in accordance with Clause 11
(x) Complying circulation spaces

The hoist must—

(a) provide a constant charge in-line room coverage hoist system (also known as an “XY” system or gantry) including 2 parallel fixed rails and a moving traverse rail; and

(b) provide coverage over the entire room; and

(c) have a maximum safe working load of not less than 180 kg; and

(d) be capable of sustaining a static load of not less than 1.5 times the rated load; and

(e) have a maximum lifting height of 2100 mm

(a) The change table must be—

(i) permanently installed, with one of the long edges up against a wall and with a retractable safety rail on the opposite side; and
(ii) motorised for the purposes of height adjustment; and
(iii) height adjustable between 450 mm and 900 mm above finished floor level; and
(iv) not less than 700 mm wide; and
(v) not less than 1800 mm long

(b) The change table must have a maximum safe working load of not less than 180 kg, including when raising or lowering the table

(c) The change table must not encroach on any required circulation space

(d) A dispenser for sanitary wipes must be provided

(e) A shelf not less than 400 mm long and 150 mm wide must be provided

We are here to help

Our friendly team understand BCA compliance requirements and are keen to share their knowledge and experience so you can be confident in the selections you make. We stock a range of ceiling hoists and change tables that meet specifications.

Get in touch today to discuss your specific requirements. Call us on 1300 444 600 or complete our quote or enquiry form and we will be in touch.
